Dust-free Clean Electric Hoist

Descrizione

Dust-free clean electric hoist is specially for lifting equipment in dust-free workshops, food and medicine, electronic precision manufacturing and other occasions where cleanliness are strictly required. Its design core is dustproof and pollution-proof, and it also ensures stable and reliable lifting performance. Its biggest feature is its fully enclosed dust-proof structure to ensure that there is no particle pollution during lifting. The whole machine is made of stainless steel or anti-corrosion aluminum alloy, with a smooth surface. This is convenient for cleaning and disinfection, and can resist corrosion of commonly used chemical solvents in the workshop.

The hook is mirror polished to reduce dust adhesion. And wire rope is replaced with stainless steel coated tube or polyester fiber coating to make sure cleanliness. Users could also choose high-strength polyester suspenders to replace metal cables to further reduce the risk of pollution. Key components such as limit switches are also sealed to prevent particulate matter from entering and affecting accuracy.

The control box adopts a fully sealed structure, and the buttons are replaced by silicone buttons or touch screens to avoid particles caused by mechanical wear. with wireless remote control to reduce surface contact contamination of the equipment. The operating noise of the whole machine is controlled below 60 decibels, which meets the strict requirements of the sound environment of the clean workshop.

Caratteristiche

• Fully enclosed dust-free design
• It adopts a 304 stainless steel integrated molded shell and mirror polishing to completely eliminate dust generation. The motor and the transmission system are sealed in multiple layers to ensure zero pollution during operation and meet the ISO Class 4 or above clean standards.
• Oil-free anti-fouling transmission
• Innovative magnetic sealing technology to eliminate traditional gear lubricating oil. It uses self-lubricated bearings and ceramic coated parts to completely avoid oil leakage and is suitable for high-demand environments such as food and medicine.
• Silent low-cost operation
• Equipped with a brushless servo motor, noise is less than 55 decibels. Intelligent frequency conversion control, energy consumption is 40% lower than that of ordinary models, and is energy-saving and environmentally friendly.
• Intelligent control system
• Supports dual modes of touch screen and wireless remote control, and has built-in running data recording function. It can monitor the status of the equipment in real time and realize remote fault diagnosis.
• Quick cleaning and maintenance
• Modular quick-disassembly structure, deep cleaning can be completed within 30 minutes. All interfaces are dust-proof, no professional tools are required for maintenance, which greatly reduces downtime.

Parametri tecnici

Certificato
